POST limitations between Add & Edit?


This works without any issues.

I am working on a button that opens the signature to allow editing it. When I save the edited signature I get an HTTP Error 400: The size of the request headers is too long. When I look at the URL it has the entire DataURL along with the encoding for special characters like '+', so the payload is constructed correctly.

So the DataURL POSTs with no issue when I add, but it is too long when I edit. Is there a different limitation for edit versus add? Otherwise I see no reason why I get this error.

Here is an example of a captured signature displayed in the native Quickbase form:

Here is what it looks like in the custom form:



------------------------------
Adam Keever
------------------------------
